How to make a debian linux machine Ansible ready

This document shows how to prepare a debian linux machine to connect to Ansible (or to get the machine ansible ready so that you can configure it using ansible). This is a very simple example that shows Ansible prerequisites.

Ansible prerequisites

Very simple prerequisites :

  • You can ssh into your ansible-managed server
  • The ssh client public key is installed on the server so that the client can authenticate automatically and securely
  • Python is installed on the server so that Ansible can execute tasks
  • The server is identified either by its name or its ip address
  • The server is connected to the Internet (it’s not a prerequisite of Ansible but it’s a prerequisite to install it as follows)

Deployment scenario

As a first step with Ansible, we may imagine that you deal with a few machines (10 servers for instance), and that network addresses are statically assigned or that the servers are registered in the DNS.

Adjusting network parameter

Debian version < 9

$su
$ vi /etc/network/interfaces
allow-hotplug eth0
iface eth0 inet static
  address AAA.AAA.AAA.AAA  # REPLACE WITH YOUR OWN VALUE
    netmask 255.255.255.0
      gateway GGG.GGG.GGG.GGG # REPLACE WITH YOUR OWN VALUE
      $vi /etc/resolv.conf
      nameserver NNN.NNN.NNN.NNN # REPLACE WITH YOUR OWN VALUE
      $service networking restart
      $vi /etc/hostname
      couchbase1
      $vi /etc/hosts
      127.0.0.1       localhost
      127.0.1.1       SERVERNAME # REPLACE WITH YOUR OWN VALUE

Debian version >= 9

You may notice that there is a new instruction in /etc/network/interfaces :

source /etc/network/interfaces.d/*

This instruction requires the network daemon to configure interfaces by executing scripts located in /etc/network/interfaces.d and then to fall back to the default configuration defined in /etc/network/interfaces.

Consequently, you should let /etc/network/interfaces file as it is and add a file in interfaces.d directory :

$vi /etc/network/interfaces.d/
auto
iface  inet static
address AAA.AAA.AAA.AAA
netmask NNN.NNN.NNN.NNN
gateway GGG.GGG.GGG.GGG

Openssh

Install openssh-server on the ansible target (or another ssh server):

$su
$apt-get install openssh-server

Check that you can ssh into your server using your login/password.

Adding an account with public key to the server

Create a new account on the server

We create a new user “ansible”. This account will be used by ansible to connect on the target server. You may as well connect with another regular linux account. We choose to create a specific account to be consistent across our servers (same account, named ansible, on every server).

$adduser ansible
...

Create a public/private keys pair on your client

Ansible requires that the account used to connect to the configured server authenticates with private/public key.

USER = your local account

First, generate a key pair on your local machine :

LOCAL$cd
LOCAL$mkdir .ssh
LOCAL$chmod 700 .ssh
LOCAL$ssh-keygen -t rsa -b 2048
Generating public/private rsa key pair.
Enter file in which to save the key (/home/USER/.ssh/id_rsa): /home/USER/.ssh/ansiblekey
Enter passphrase (empty for no passphrase): **********
Enter same passphrase again: **********

Then, copy your public key to the remote server :

LOCAL$ssh-copy-id -i /home/USER/.ssh/ansiblekey.pub USER@SERVER

Finally, register your credentials in your local ssh client configuration :

LOCAL$cd
$vim .ssh/config
Host SERVER
    HostName SERVERIP
    User USER
    IdentityFile ~/.ssh/ansiblekey

Add ansible account to sudoer group on the server

The ansible account on the server should have sudo privilege without password :

  • sudo must be installed on the server
  • add the user ansible to sudo role without password
log into the server
$su
$apt-get install sudo
$cd /etc/sudoers.d/
$visudo -f ansible
ansible ALL=NOPASSWD: ALL
$chmod 0440 /etc/sudoers.d/ansible

Install python on the target server

We work with python. Ansible compatibility with python 3 is rather fresh. We’ll upgrade when we need to…

LOCAL$ssh ansible@SERVER
$sudo apt-get install python

Improvements

Should you have to manage many Ansible servers, you’ll probably instantiate some kind of directory

  • when a server fires up, it gets its parameters by Net boot and then registers automatically to the directory and the DNS
  • credentials are managed centrally by a PKI server

And you’re done :-) !
